Project Description

CHHJ-160SC-N Bench Socket Fusion Machine

☆ Removable tripod stand main frame, convenient for construction site and flat ground.

☆ Intelligent temperature control box, it can weld various material.

☆ Self-centering function.

Fusing pipe scope 50MM~160MM
Rated voltage A.C 220/230V, 50/60Hz
Power 1800W
Working temperature 200~279℃±1%
Environment temperature -5℃~45℃
Applicable material PP-R,PE,PP,PB,PVDF
Net weight of machine 130kg
Carton size 1100*820*760mm

☆ 1 PCS fusion tool

☆ 1 PCS metal case

☆ 1 PCS underpin stand

☆ 1 purchase table-board clamp(optional)

☆ 1 bag of bolts and hex key wrench

☆ Sockets D20, D25, D32*, D40*(optional)
